Product Brand: Phönix
Supplied as Straight pattern body
Applications Description
For liquid chlorine service and similar dangerous, toxic, aggressive and corrosive media (for example phosgene)
| Specifications: | |
|---|---|
| PN | 40 |
| DN | 15 - 350 |
| Class | 300 |
| NPS | 1/2 - 14 |
| Temperature Rating | -40°C up to +120°C |
| Shell Materials |
Carbon steel Low temperature carbon steel Stainless steel Hastelloy Other special alloys |
| Connections |
Flanged ends other connections as required |
| Operation | Pneumatic piston actuator, Pneumatic diaphragm actuator |
| Approvals | euro chlor approval 13/05 |
