Dry Evotek Adapter
DDEA200SSFL
Attributes
Weight:0 lb
Optional Package/Box Quantity:1
Size:106 mm
Flange Size:2"
Details
Applications
Specifically designed for use in the chemical industry
Rotating the coupling 120° clockwise opens the valves where the high pressure engagement between hose and tank unit ensures a strong connection
Approvals
PED 2014/68/EU 4.3
ATEX 2014/34/EU Category 3G
Construction
Body: stainless steel 1.4404
Handle: PE (DN40 and bigger)
O-rings: FPM, NBR, EPDM, FFKM
Thread seal: PTFE, FDA and others upon request
Description
Adapter x 150# Flange
Features
Low connecting forces even against pressure
Ergonomic handle (DN40 and bigger)
Good transmission ratio in the cam curve
Wide range of chemical resistance due to high-quality material selection
Minimized spillage during de-coupling
Safety Notes
WARNING: This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
Specifications
Working pressure 360 PSI at ambient temperature 70°F (21°C)
